More Details

Frame
* Rigid, steel frame
* Mid wheel drive

Seat
* Fully upholstered vinyl with foam padding.
* Option of fitting Leckey Mygo seating system.
* Can accommodate a range of seating systems

Upholstery
* Synthetic (vinyl and other)

Backrest
* Rehab (340 - 610mm wide), custom bolsters, foam in place

Headrest
I* Standard

Armrests
* Arm pads 100mm, 75mm, waterfall, gutter, gel

Legrest
* Centre post, side mount, drop in, swing away

Footplates
I* One or two piece fixed/flip up/angle adjustable

Postural accessories
* Pads and supports include knee, hip, abduction, thoracic
* Straps and harnesses include chest, ankle, harness, posture belts

Wheels
* 320 mm (12.5 inch) Alloys with split rims

Castors
* 175 x 40 mm

Brakes
* Automatic

Controls
* Dynamic DX2 as standard
* Compatible with the DX-ECU Environmental Control Unit.

Batteries
* 40 Amp/hr

Motor
* 68Nm Torque, 800W, GIL

Transport or Dismantling
* Wheelchair does not dismantle

Option Details
* Special Controls include head, attendant, chin, foot, environmental
* Power options include 300mm seat elevation (lift), seat tilt (up to 50), power legrest, power backrest, anti-shear backrest

Considerations

Transport Accessibility
The space allowed on public transport for carrying mobility equipment is an area of 1300mm by 800mm.

Wheelchair spaces
All new Sydney buses feature special 'kneeling suspension' and a ramp to provide easy access for less mobile passengers.

There are spaces for two wheelchairs on the new buses. These will accommodate most manual and electric wheelchairs with maximum length 1250mm, maximum width 750mm, maximum turning circle1500mm and maximum weight 200kg.

For safety reasons, passengers in wheelchairs are advised to face the back of the bus, bracing their wheelchair against the side of the space, applying the brakes and securing the seat belt of the wheelchair.

Wheelchair accessible buses display a blue and white wheelchair sign on the front of the bus, and on the easy access door.

Occupied Wheelchair in a Car
A person sitting in a wheelchair within a car or van requires certification and RTA approval for the wheelchair and occupants restraint system where the wheelchair or occupant are restrained to the vehicle structure. RTA approval is not required for a postural support, such as a harness, that is only attached to the wheelchair and not to the vehicle.

Wheelchair Restraints
When transporting a person in a wheelchair in a car or van, both the occupant and the wheelchair require an RTA approved restraint system. The wheelchair and the occupant need to be separately secured to the vehicle itself.
RTA approval is not required for a postural support, such as a harness, that supports the user in the wheelchair but is not part of the vehicle restraint system.
The use of a headrest is not legally required but strongly recommended. Easily detachable, folding headrests which fit a wheelchair with standard push handles are available. Refer to section Wheelchair, Scooter, Cushions, ramps / Postural Supports - Seating System: Restraint+ Head+Back+Seats

Place Of Manufacture

Magic Mobility (Victoria, Australia)

Price Guide

Contact supplier for pricing

Models

The Frontier V6 is available in 5 different mid wheel drive models plus a rear wheel drive and a front wheel drive version.

Options

* Power options
* 24 volt LED lights
* Special controls
* Drop down joystick mount
* Swing away joystick mount
* WC 19 tie downs
* Bag hooks
* Pockets
* Sheepskin
* Tables
* Cup holder
* Cane holder
* Ventilator carrier

Additional Dimensions

Length Overall 890 mm
Height of Seat Rear 425 mm (without cushion)
Diameter of Castor 200 mm
Diameter of Mid Wheel 318 mm
Width of Castor 50 mm
Width of Wheel 57 mm
Top speed 10 km/hr

Maintenance

All wheelchairs require regular maintenance. Refer to User Manual for specific details

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.

Licence & Insurance Requirements

In NSW, motorised wheelchairs that weigh less than 110 kg and cannot travel at more than 10 km/h do not have to be registered, provided they are being used by a person with mobility problems. A person driving a motorised wheelchair under these circumstances is defined as a pedestrian under the Australian Road Rules and is permitted to travel on a footpath or nature strip adjacent to the road.

Vehicles exempt from registration are covered by the nominal defendant scheme (administered by the Motor Accidents Authority) if they are at fault in an accident in NSW on a road or road-related area and cause injury to another person. However, this cover is only valid in NSW.
