Short Description

A free standing, electrically height adjustable bath mounted on height adjustable legs. Can be supplied with tapware installed on unit or tapware can be fitted to the wall. A model with an integral spa is available. Available in two sizes.

Options

. Foot control or hand switch
. Portable steps and hand rail assembly to incorporate with bath for assisted access. Wheels under bath bottom frame and secures to floor via rubber padded slide bolts.

Models

1) Standard Easy Way adjustable height bath without tapware
2) Standard Easy Way adjustable height bath with tapware
3) Air Spa Easy Way adjustable height bath without tapware
4) Air Spa Easy Way adjustable height bath with tapware

More Details

. Has an Occupational Health and Safety Registration No. G.351
. Designed for hospitals, nursing homes, rehabilitation centres.
. Complies with Australian Standard AS 3100 -1990 including amendments 1,2,3.
. Easily connected to existing plumbing services.
. 120mm clearance underneath allows use of mobile hoist for transfers.
. The Easy Way Bath is designed to allow for bathing at a range of heights, to lessen back strain for carers / staff.
. The Air Spa bath has 14 spa Jets & Purge cycle to fully drain the manifold system following bath use (providing infection control).
. The bathing assembly is able to pass through standard width doorways.
. It incorporates a standard pressed steel bath insert (400mm depth) which may be removed / replaced with a minimum of inconvenience.
. Optional Tapware Header Panel consists of fibreglass bulkhead attachment to head of bath and incorporates Grohe Euroeco Bath Taps and Hand Shower and 2000 series thermostatic mixing valve.
. The surrounds are made of fibreglass.
. Can be supplied with taps, outlets and thermostatic mixing valve temperature control.
. 120mm clearance underneath allows use of mobile hoist for transfers.

Operation :
. 24 volt hand held heavy duty waterproof actuator system with battery back up. Optional foot control.
. A circuit breaker is required at the 240v supply point.
. Water and waste pipe connection must be done by a registered plumber.

Installation

. Installation of bath including water, power and water pipe connections to be completes as part of the building works contract, by suitably qualified personnel.
. The Red Plaque (supplied) which lists instructions on bath use, must be adhered to the back of the wall where the bath is positioned.

Maintenance

Observe operation and maintenance instructions provided by manufacturer.

Place Of Manufacture

Easy Way Bath Pty (TAS)
Australia
