Short Description
This electrically powered hydrotherapy system includes the fixed Entroy pool lift and the Entroy pool lift chair or stretcher with chassis. Lifting, lowering, turning and backrest adjustments on the stretcher are operated from a handset. The lift arm is rotated electrically or manually. The system can be customised with various options. Lifting capacity is 160kg.
Options
The Entroy pool lift system can be customised to fit the specific needs of patients and enhance the working environment of therapists by choosing between the following options:
Manual or powered pool lift arm turning - Electrically powered turning minimises the physical demands on the therapist and enables those patients who are capable of transferring independently to do so.
Chair options: The alternatives are: a chair that is fixed to the lift arm, or a chair that is part of a transfer system that includes quick coupling and combination with a chassis for transport.
Stretcher options: The Entroy stretcher is always part of a complete transfer system with quick coupling and chassis. The stretcher chassis combination can be driven manually. Alternatively, a chassis with power drive minimises the effort of driving.
Models
Entroy Pool Lift model GAB 1000-01 (manually rotated)
Entroy Pool Lift model GAB 1000-11 (electrically rotated)
| Specification |
Standard |
| Boom Rotation |
Unknown |
| Load Capacity (supplier stated) |
From 160 kg to 200 kg |
| Seat Depth |
Unknown |
| Seat Width |
550 mm |
| Spreader Bar Height |
Unknown |
Additional Dimensions
Height NSW........................................................ From 495 mm to 1095 mm
More Details
The Entroy is designed to lift an immobile person comfortably into the pool either seated on a chair or lying on a stretcher. It offers a complete transport and transfer solution for all stages of the hydrotherapy cycle.
One carer can manage pool access and exit routines for recumbent or sitting persons with the Entroy pool lift and transferable stretcher or chair. If a fixed Entroy pool lift chair is used, users can transfer directly from a wheelchair or walker.
Features:
Materials:The lift construction is made mainly of aluminium and stainless steel in combination with plastic details. The colours are grey and blue with red details matching the stretcher and chair.
Base Plate: bolted to the floor next to the pool
Mast: Vertical
Boom:(or lift arm) is rotated electrically or manually and can be delivered in different lengths. The chair or stretcher can be manually rotated by pushing the lift arm.
Seat: plastic seat with back rest. Drainage hole in seat and back. The chair can either be fixed on the lift or equipped with a quick coupling which enables a transfer from a mobile chassis to the lift arm. The chair user needs trunk stability.
Stretcher: equipped with a quick coupling which enables a transfer from a mobile chassist to the lift arm. Optional chassis power drive. The submersible soft stretcher can also be used for bathing and showering.
Armrests:on chair - lift up
Action: vertical vertical
Power Source: rechargeable batteries 24V, 4 amp/hr
Number of lifting cycles with one battery 15 (with 75kg person)
Battery Recharging: the batteries are removed and charged in the charging unit placed in a dry place
Method of Operation:The person has to transfer into the chair or other optional attachments at pool side and then uses hand held controls to lower into the water and reverse to get out. The hoist can also swing out over the water automatically or manually.
Portability: mast is fixed - not portable
Safety Features: Complies with CE marking for electrical and mechanical safety, electromagnetic compatibility and hygiene. Contact supplier re: compliance with relevant Australian Standards.
Customoised Features: see options
Installation
The installation of a pool lift must fulfil the local regulations for building and electrical standards.
Standards
Specific Australian Standards or other Standard(s) may be applicable for materials, manufacturing processes, or installation of some types of equipment. Compliance with relevant Standards is indicated by written certification that a product has been tested and assessed as compliant with specific Standards. Purchasers are advised to check with the supplier or manufacturer of this item as to its compliance with relevant Standard(s).
Place Of Manufacture
Sweden
