More Details

* Please note the measurements specified in key dimensions are taken for the Jewel Tilt-in-Space model with headrest extension, recline and tilt mechanism in upright position and elevating footrests in lowest position

Frame
* Rigid frame

Back
* Recline is standard. Operated by turning a handwheel to the side of the seat. This causes the backrest to recline or come forward
* A small lift-up lever, located next to the handwheel allows the backrest to be raised to vertical position temporarily

Seat
* Padded and contoured seat with standard widths 410 and 460mm
* Customisation of seat size and supports available
* Moulded seating available
* Headrest extension as standard
* Upholstery has various types available including vinyl

Armrests
* Height adjustable using an allen key
* Removable
* Padded and extend to the end of the seat
* 100mm width armrests

Legrests
* Elevating footrests are optional
* Made to the size of the individual
* Have padded calf pads, a lever to lock and unlock the elevated position
* Can be swung away and removed

Footrests
* Flip up, swung away and removable as standard

Castors
* 190mm spoked castors as standard
* Many other options such as MCP castors available

Wheels
* Available with attendant propelled size wheels only which are 310mm diameter as standard
* Pneumatic wheels are standard but can have other options such as solid rubber

Brakes
* Lever action, fixed to the lower part of the frame

Customisation
* A large degree of customisation is available to the entire wheelchair

Dismantling
* Pull out bar under seat and remove pin from gas tilt mechanism to lift seat off base
* Components are heavy

Place Of Manufacture

Magic Mobility (Vic)
Australia

Price Guide

Contact supplier for pricing
Price on application from GTK Rehab

Options

* Neck Pillow
* Elevating Legrests
* Harness
* Customised Contouring
* Narrower Armrests

Additional Dimensions

Length........................ 1145mm
Height......................... 1175mm
Width............................ 645mm
Seat Height................. 550mm
Seat Rear Height........ 480mm
Seat Front Height....... 550mm

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.
