More Details

Frame
* Lightweight, anodised aluminium framework to which positioning components are attached
* Each support is horizontally and vertically adjustable and swings away to facilitate transferring in/out of the chair
* There is a large range of options and accessories

Seat and Backrest
* One piece double thickness, washable vinyl nylon
* Provides back height and seat depth growth and adjustments
* 2 way back tension and 4 way seat tension adjustments
* Removable without tools
* Internal 20 mm neoprene back pad with stiffener included
* 2 sling styles: Standard - unit tensing of seat and back. Kyphosis - separate tensioning of seat and back

Legrests and Footrests
* Legrest angle adjustable in 12 degree increments
* Detaches from seat when adjustment knobs are released

Bases
* Tilt-in-space base
* Folding bases with large wide profile wheels
* Front strut option enables seat to detach quickly from base
* Rigid base designed for stability with low maintenance wheels

Options
* Stainless steel back bars
* Knob locks to prevent casual readjustment of positioning angles
* Lock nub to prevent casual vertical readjustment
* Seat pads, back pads, lumbar pad, hip belt and safety harness

Assembles For
* Neckrests, halos, shoulder pads, thoracic, pelvic, hip and thigh supports
* Knee blocks
* Armrests with hip/thigh supports
* Trays - ABS plastic or clear acrylic

Place Of Manufacture

MULHOLLAND POSITIONING (USA)

Options

* Symmetrical or asymmetrical individual footrests
* Height adjustable epoxy finished aluminium footplate
* Independently adjustable shoeholders that allow individual adjustment for height, width, dorsiflexion/plantarflexion and inversion/eversion
* Full width footrest
* Travel Yoke ie narrow footrest to facilitate car transfers
* Full footrest pad
* Ankle cuffs.
* Foot guides

Accessories:
* Canopy assembly
* Utility bag

Additional Dimensions

Infant Toddler
Lateral Hip Width (Front) 215 - 335 mm
Lateral Hip Width (Rear) 140 - 250 mm

Junior
Lateral Hip Width (Front) 305 - 440 mm
Lateral Hip Width (Rear) 230 - 380 mm

Toddler
Lateral Hip Width (Front) 265 - 335 mm
Lateral Hip Width (Rear) 140 - 250 mm

Youth
Lateral Hip Width (Front) 280 - 390 mm
Lateral Hip Width (Rear) 190 - 330 mm

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.
