More Details

Frame
* The frame is adjustable to accommodate for growth

Upholstery
* The seat has two heavy duty, reinforced upholstery pieces
* The lower seat panel is attached to the back panel with hook and loop tape. It can be adjusted after seat depth adjustments have been made
* The upholstery can be removed from the frame for cleaning

Seat
* The seat features in built lumbar support and 20 degree fixed tilt at shoulder level
* An adjustable three point positioning belt is standard. It features a metal buckle which connects the three straps

Backrest
* Features removable rigidisers and is height adjustable
* Extensions are optional
* It folds down for storage and transport

Adjustments
* The buggy has adjustability in terms of seat width, seat depth, backrest height and seat height
* The buggy also features adjustable backrest recline and tilt in space. Recline angle can be set at 85, 90 or 95 degrees. Adjustments are achieved by using an allen key

Armrests
* Lift up with foam padding

Rear Wheels
* 310mm diameter, fixed knobby pneumatic tyres

Front Castors
* 200mm diameter, swivelling ribbed pneumatic tyres

Footrests
* Two piece lift up, swing away footplates with height adjustability, depth adjustability and are removable via a pin lock

Brakes
* Activated by hand controls located on the push handles
* Additional pull on manual parking brakes are located on the rear wheels

Transporting
* The buggy can be folded for storage and transport

Method Of Use

To Fold
* Before folding, the front wheels of the chair should be facing forward
* Release the hook and loop tape closure strap
* Unlock the rear brace by pushing up on the centre of the brace with your foot
* Flip the armrests up and swing the footrests to the side
* Grasp one push handle and with the other hand, pull up on the middle of seat upholstery
* Lay the buggy flat with the seat facing upwards. Push on the tubular seat bars or the footplates to complete the fold
* Move the buckle or closure strap to an appropriate length and wrap it securely around the chair and lock

Place Of Manufacture

USA

Price Guide

Price is from Aidacare

Models

* Scout Basic: has all the standard features
* Scout Transport: all the same features as the Scout Basic with bus / van tie down anchors. It has a reinforced frame, reinforced upholstery and reinforced crossbrace. This model includes H-harness with padded strap covers and headrest extensions

Options

* Range of wheel sizes / types
* H harness with padded covers
* Swing-away adjustable lateral supports
* Full torso swing away support vest
* Adductor
* Abductor
* Padded neck support
* Headrest extension
* Foam wedge
* Foot positioner straps
* Tray
* Canopy
* Grab bar

Additional Dimensions

SC12
Width..................620mm
Length................1300mm
Height.................940mm
Folded Length........1330mm
Folded Width........405mm
Folded Height........420mm
Seat to footrest......100mm-635mm

SC14
Width..................660mm
Length................1370mm
Height.................965mm
Folded Length........1320mm
Folded Width........405mm
Folded Height........390mm
Seat to footrest......75mm-590mm

SC16
Width..................710mm
Length................1395mm
Height.................990mm
Folded Length........1400mm
Folded Width........405mm
Folded Height........380mm
Seat to footrest......140mm-570mm

SC18
Width..................775mm
Length................1420mm
Height.................990mm
Folded Length........1450mm
Folded Width........405mm
Folded Height........420mm
Seat to footrest......250mm-610mm

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.
