More Details

* Zero wall proximity - operates 100mm from wall

Frame
* All frames are made from plantation pine and are glued, blocked and nailed

Uphostery
* Suspension is Zig Zag springing
* Premium high resilient foam
* European Dacron back cushions
* Available in leather
* A wide range of fabrics is available. Crypton waterproof fabrics available on request

Controls
* Controller can be placed either left or right side - right side by default
* Dual motor mechanism available for complete layout operation and independent foot and backrest operation

Motors
* All chairs are available with single motor (Omega 1) or Twin motor full layout with independent control of foot and back (Omega 2)

Footrest
* Integrated
* Spring loaded footrests for extra safety

Castors
* Mobile on castors for ease of movement. Castors disengage when lift and recline adjustments are operating

Safety
* Battery backup in case of power failure. It returns chair to home position - must be replaced after one operation
* Spring loaded footrests

Place Of Manufacture

NSW Australia

Price Guide

Prices from ILS

Models

The Range Consists of the Following

Moritz XL270
* Very high capacity twin motor electric lift (lift capacity 270kg seat width 82cm overall width 129cm)
* This chair is constructed from marine ply and is braced with steel brackets and has 200 grade foam in the seat

Moritz XL200
* Mid capacity single motor electric lift chair (lift capacity 200kg seat width 66cm overall width 111cm)
* Same construction as XL270

Aspen, Brooklyn, Coventry, Erin, Paris, Collette
* Spacesaver single motor general use electric lift chairs (lift capacity 125kg)
* The Spacesaver is the same as the Collette but with a smaller arm
* Erin Petite electric lift chair single or twin motor ( 7.5cm lower and smaller all round than normal chairs 125kg lift capacity)
* Collette Petite electric lift chair single or twin motor ( 7.5cm lower and smaller than normal chairs 125kg lift capacity)

Aspen, Coventry, Erin, Paris, Collette
* Spacesaver Twin motor electric lift chair 125kg lift capacity (twin motor allows full layout however these are not recommended to be slept in on a regular basis)

Options

* Headrest
* Arm covers available on request
* All chairs can be integrated into a suite
* Dual motor mechanism
* A wide range of fabrics including Crypton waterproof fabrics

Additional Dimensions

Aspen & Brooklyn
Width..................................... 980 mm
Length.................................... 900 mm
Height.................................... 1020 mm

Coventry
Width..................................... 870 mm
Length.................................... 900 mm
Height.................................... 1020 mm

Moritz XL200
Width..................................... 1110 mm

Moritz XL270
Width..................................... 1290 mm

Paris
Width..................................... 940 mm
Length.................................... 900 mm
Height.................................... 1020 mm

Spacesaver
Width..................................... 730 mm
Length.................................... 900 mm
Height.................................... 1020 mm

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.
