More Details

Frame
* Rigid frame with a steel gear rack and teeth, and aluminium side frames

Seat
* Solid seat pan with 100mm seat width growth with all 4 sizes

Backrest
* Available with fixed or fold-down backrest canes for transportation

Armrests
* Fixed height desk and full length armrests are standard

Legrests
* 60, 70, and 90 degree swing-away leg rests are standard

Footplates
* Flip- up footplates are standard

Wheels
* Urethane tyres
* Quick release axles available
* Different sizes available - 12" to 24"

Castors
* 5" semi pneumatic, 6" urethane 3 spoke or 8" urethane castors

Mechanism
* Weight shift tilt in space is designed to maintain the position of the users centre of gravity. It eliminates tilting the user around a fixed pivot point
* Method of use is a combination of pressing down on the push handles whilst depressing the lever located underneath the push handles. The pivot point moves constantly along the gear rack to maintain the position of the users centre of gravity. Tilt lock out levers, and push or pull to lock wheel locks are standard

Place Of Manufacture

USA

Models

One model available in 4 seat width ranges:
* 12" to 16"
* 14" to 18"
* 16" to 20"
* 18" to 22"

Options

* Heavy duty package
* Reclining backrest and rigidising handle bar
* Adjustable height desk and full length armrests
* Adjustable height T- arm desk and full length armrests
* Drop mounted aluminium seat pan
* Pneumatic and flat free tyre inserts
* Plastic coated hand rims (pair) - vertical and oblique
* Foot operated, cane mounted, and seat rail mounted hub locks
* 70 and 90 degree lift- off footrests, elevating leg rests, contracture footplates / platform, impact guards
* Calf strap, heel and toe loops
* Ventilator tray
* Various stealth headrests
* Positioning strap and belts
* Tie downs

Additional Dimensions

Tilt Angle....... -5degr. to 50degr.

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.
