More Details
Frame
* The TiLite Rigid Folding Mechanism (RFM) cross tube design allows one piece side frames which reduce flex because the side frames are welded instead of bolted
* This can improve efficiency when pushing the wheelchair
* The RFM cross tubes feature snap in seat saddles that lock into place
* The tubing is Ti3-2.5 seamless aerospace grade titanium improving vibration dampening
* Satin or polished frames are available
* The titanium also increases durability of the frame
* Anti tip bars are optional and come in black aluminum
Seat
* A range of seat widths, depths and heights are available
* A range of cushions are available including foam cushion, stimuLITE sport, corbee, ROHO low profile quadtro select, ROHO custom, varilite evolution and varilite ziod. The cushion depths, widths and thicknesses depend on the cushion style chosen
Upholstery
* The standard upholstery colour is black. Ti red, royal blue, navy blue, digital camo, hunter green and purple are optional
* The back upholstery comes in padded nylon as standard and optional tension adjustable straps
* The seat upholstery comes with tension adjustable straps as standard
Backrest
* A range of backrest heights are available in 25mm increments
* The standard seat back is a straight back
* Optional seat backs include straight with push handles integrated on the back posts, straight with bolt-on height adjustable push handles, eight degree bend, or eight degree bend with push handles integrated on the back posts
* All back rests can come with optional folding stabilizer bar
Armrests
* Three optional styles of armrests are available in heights of 230mm to 305mm, or 305mm to 380mm
* All three styles come with the optional cover of black alcantara ultrasuede
* All arm rests are optional
* Armrest choices include swing away tubular, removable height adjustable desk arms with rigid side guard, with or without transfer loop
Legrest
* The swing away, removable legrests come in 70, 80, 85 and 90 degree front angles with no taper as standard
* An 80 degree front angle with 50mm taper and no hangers are optional
* The fixed legrest comes in a 70, 80 or 85 degree front angle with no taper as standard
Footplate
* Lift up footplates come standard
* Footplate options include one piece, lift up footplate, depth adjustable lift up footplate, depth and angle adjustable lift up footrest, or angle adjustable lift up footrest
* Several seat to footplate lengths are available
* Heel loops are optional
Wheels
* There are 50 rear wheel options available in various sizes
* The spinergy wire wheel with low flange hub comes standard
* Other options available are the tilite wheel with high flange hub, spinergy spox, spinergy LX and skyway mags
* Pneumatic rear tyres come with treaded or primo treaded as standard
* Eight other styles are available
* Three optional solid rear tyres are available
* There are nine push rim options available
* Aluminum or long tabs come standard
* Other options include titanium, natural fit (regular or super grip), plastic coated, eight vertical projections, short tabs or no push rims
* Optional wheel locks include standard push to lock, scissor, uni lock (set at push or pull) or uni lock extension handles
* Optional quick release wheels are available in stainless or titanium
* Also quad release and amputee axle plates available
* Standard camber range includes 0, 2, 4, 6 or 8 degrees
* Additional camber plug (pair) in the same range is available
Castors
* There are 18 castor options available in various sizes
* Plastic wheels with polyurethane tyres come standard
* Optional front wheels include micro castor, light up micro castor and billet aluminum (with polyurethane or soft roll tyre)
* Other options include frog legs - suspension forks and castor pin locks
Centre of Gravity
* The wheelchair has an adjustable centre of gravity axle feature involving the Tru-Fit clamp on component system comprising of the Rigid Folding Mechanism, rear axle plate and front castor clamp. These components all clamp on to the frame instead of being bolted through resulting in a 50% reduction in the holes in the frame
Considerations
Wheelchair Restraints
When transporting a person in a wheelchair in a car or van, both the occupant and the wheelchair require an RTA approved restraint system. The wheelchair and the occupant need to be separately secured to the vehicle itself.
RTA approval is not required for a postural support, such as a harness, that supports the user in the wheelchair but is not part of the vehicle restraint system.
The use of a headrest is not legally required but strongly recommended. Easily detachable, folding headrests which fit a wheelchair with standard push handles are available. Refer to section Wheelchair, Scooter, Cushions, ramps / Postural Supports - Seating System: Restraint+ Head+Back+Seats.
Place Of Manufacture
USA
Price Guide
Call supplier for pricing
Price on application from GTK Rehab
