More Details

Frame
* The scooter has an epoxy coated, steel frame, moulded plastic cowlings, a metal protection rail at the front of the base and fabric matting on the foot platform
* It has loop handlebars
* The scooter can be free wheeled by lifting a lever located at the rear, right hand side of the base
* It has anti-tip wheels at the rear
* The scooter has front and rear adjustable, spring suspension

Accessories
* A basket at the front is standard
* Headlight, taillights and indicators
* Two rear vision mirrors

Seat
* It has a standard folding 360 degree swivel Captain's Seat (foam padding with vinyl upholstery) with an adjustable height headrest
* The seat position is depth adjustable using a lever on the side
* It is available in one seat width and one seat depth
* The seat height is adjustable
* The seat is reclining

Backrest
* It has a vinyl covered, padded and contoured backrest with an adjustable height headrest
* The backrest is angle adjustable (25 degrees of recline) and available in one height only

Armrests
Full length, lift up, width and height adjustable armrests are standard

Wheels
It has pneumatic 300mm diameter tyres that are 90mm wide

Controls
* It has a dynamic 110Amp controller
* The controls include buttons for headlight, horn and turn signals
* IIt also has a battery indicator and speed selection
*. It has finger controls for driving forward and reversing
* A diagnostic light flashes a sequence to assist in determining the cause of a fault in the scooter. The owner's manual has a chart to explain what each sequence of lights means
* There is a manual hand brake on the tiller handle that can be used to brake the front wheels if needed

Batteries
* It has two DC12Volt batteries (50Amps per hour)
* The battery Charger is a 5 Amp Offboard charger

Motor
* It has a 4 pole, 24 Volt motor
* The motor can be disengaged for freewheel mode
* It can drive up a 12 degree maximum incline

Dismantling
The scooter is not suitable to break down for transport

Colours
It is available in metallic grey or sky blue

Brakes
It has electromagnetic drum brakes

Considerations

Transport Accessibility

The space allowed on public transport for carrying mobility equipment is an area of 1300mm by 800mm.
Overall length of this scooter ...........1280 mm
Overall width of this scooter ........... 660 mm

State transit will only carry scooters with an unladen weight of less than 200 kg and which can be driven onto the bus, and manoeuvred to fit wholly within the designated wheelchair space under their own power. Any such scooters carried must also comply where relevant with the rules applying to wheelchairs.

Three wheeled mobility aids of any kind are unstable in normal bus operations and will not be carried because of the safety risk.

Accessible buses display a blue and white wheelchair sign on the front of the bus, and on the easy access door.

Factors applying to all scooters
* This item should be trialled in the user's own environment to ensure maximum safety and independence. Environmental considerations include eg: kerbs, footpaths, tram and railway crossings, street crossings, etc
* Users should take care when riding a scooter or powered wheelchair and observe the following safety guidelines:
* Users who intend to use scooters or powered wheelchairs must ensure they have the necessary physical and cognitive skills to operate and manoeuvre them safely
* Stay within the legal speed limit of 10km/h
* Be aware that taking medication or driving under the influence of alcohol may affect the user's judgement
* Always make sure that you are clearly visible, particularly at night or on dull days-use the lights and reflectors and install a reflective flag high enough to be seen by motorists
* Wear a bicycle helmet whenever possible
* Slow down when you are near other people, especially pedestrians and cyclists
* Avoid stopping or driving on inclines greater than your scooter is designed for
* Use footpaths if possible. If there are no foot paths, plan to user quieter roads
* Plan your trip and avoid uneven surfaces, dips and potholes
* Ensure if you are carrying parcels that the load will not over-balance your scooter and the parcels do not interfere with your controls or vision

Place Of Manufacture

Taiwan

Price Guide

Refer to supplier details for pricing.

Models

There is also a three wheeled model

Options

* Crutch or Cane Holder
* Cylinder Tank Carrier
* Armrest Bag
* Backpack
* Rear Basket
* Dust Cover
* Cup Holder

Additional Dimensions

Standard
Height of Armrest from Seat...180 mm
Height Overall................1250 mm
Turning Circle................1765 mm

Maintenance

All scooters require regular maintenance. Refer to the User Manual or supplier for specific details.

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.

Licence & Insurance Requirements

In NSW, motorised wheelchairs that weigh less than 110 kg and cannot travel at more than 10 km/h do not have to be registered, provided they are being used by a person with mobility problems. A person driving a motorised wheelchair under these circumstances is defined as a pedestrian under the Australian Road Rules and is permitted to travel on a footpath or nature strip adjacent to the road.

Vehicles exempt from registration are covered by the nominal defendant scheme (administered by the Motor Accidents Authority) if they are at fault in an accident in NSW on a road or road-related area and cause injury to another person. However, this cover is only valid in NSW.
