More Details

Frame
* Folding with lock out mechanism
* The wheelchair is semi-adjustable in the seat to floor height, castors and leg rests
* Transport loops are standard
* Rear anti tip bars , adjustable and removable, with rollers are standard
* The chair is available in black frame only

Seat
* Varying seat widths and depths are available
* Depth adjustable
* Reflectors on the rear of the seat rails
* Three seat heights in 30mm increments

Upholstery
* Nylon slung style in black only
* Webbing handles to facilitate folding
* Overlap of seat upholstery to accommodate seat depth adjustment
* Seat belt is standard

Backrest
* Padded slung style
* Folds down halfway for transport
* Rubber push handles

Armrests
* Full length, solid rubber pad
* Height adjustable
* Removable with lock in pins
* Clothing guards - plastic

Legrest
* Swing away / in
* Removable, adjustable in length

Footplates
* Two piece flip up plastic
* Hook and loop adjustable heel loops

Wheels
* Solid rubber 430 mm diameter tyres are standard
* Quick release wheels
* Steel spokes
* Brushed aluminium push rims:
* There are two rear wheel positions to accommodate amputee use
* Transit rear wheel kit

Castors
* Solid rubber 200mm diameter with plastic spokes
* Two castor fork positions with 30mm increments

Considerations

Wheelchair Restraints
When transporting a person in a wheelchair in a car or van, both the occupant and the wheelchair require an RTA approved restraint system. The wheelchair and the occupant need to be separately secured to the vehicle itself.
RTA approval is not required for a postural support, such as a harness, that supports the user in the wheelchair but is not part of the vehicle restraint system.
The use of a headrest is not legally required but strongly recommended. Easily detachable, folding headrests which fit a wheelchair with standard push handles are available. Refer to section Wheelchair, Scooter, Cushions, ramps / Postural Supports - Seating System: Restraint+ Head+Back+Seats.

Place Of Manufacture

Unknown

Price Guide

Call supplier for pricing.
Price on application from ILS

Models

One model only

Additional Dimensions

Seat Height.......................460 to 510 mm
Backrest Angle....................7 deg / 0-30deg
Overall Width.....................Seat Width + 200 mm
Overall Length (Incl footrest)....1030mm - 1090mm (Self Propel)
Overall Length (Incl footrest.....950 mm ( Transit)
Turning Radius................... 88mm

Maintenance

* All wheelchairs require regular maintenance. Refer to the User Manual or supplier for specific details.

Standards

Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards
