More Details
Frame
* Rigid steel chassis
* Adjustable suspension system
* Adjustable front anti-tip wheels
Seat
* Adjustable seat width from 25 to 585mm (1 to 23 inches)
* Adjustable seat depth from 355 to 560mm (14 to 22 inches)
Options
* Power tilt-in-space from -5 deg to 45 deg or 0 deg to 50 deg
* 200mm (8 inch) power seat elevate
* Choice of Corpus 3G Ergo cushion or Corpus 3G Ergo Air cushion (with Roho insert)
* Transfer handles
Backrest
* Manual recline backrest from 85 degrees to 120 degrees
* 125mm (5") mechanical anti-shear
Options
* Power recline backrest from 85 to 175 degrees)
* Corpus 3G Ergo backrest (510mm (20 inch) fixed height; 585 to 710mm (23 to 28 inch) adjustable height)
* Corpus 3G tubular cane or direct backrest frame kit (for aftermarket seating)
* Stealth swing away lateral thoracic supports
Headrest (optional)
Options
* Corpus 3G headrest
* Stealth comfort plus headrest
* Universal headrest adaptor plate
Armrests
* Cantilever style armrests
* Adjustable height, width, angle and pitch
* Choice of 4 arm pad lengths 250, 330, 405, 460mm (10", 13", 16", 18")
* Choice of 3 arm pad styles (leatherette, mesh, and gel)
Options
* Corpus 3G arm trough adapters
* Corpus 3G arm rest side support pads
* Stealth elbow support pads
Legrests
* Centre mounted manual elevating leg rest from 85 to 170 degrees
* 7" of mechanical articulation
* Individual leg rest length adjustment from 150 to 535mm (6 to 21 inches)
Options
* Centre mounted power elevating legrest from 85 to 170
* Power transfer leg rest
* Power extending leg rest
* Amputee support pads
* Hip and thigh support pads
* Abductor pommel
Footplates
* Two piece, angle adjustable and flip back footplates
Options
* One piece footplate
* Stealth gel footplate pads
Wheels
* 14 x 3 inch drive wheels
* Choice of pneumatic or flat free (with gel insert) tyres
Option
* 14 x 3 inch pneumatic snow tyres
Castors
* 8 x 2.5 inch polyurethane castors
Controls
* R-Net electronics coupled with Intelligent Control System (ICS)
* LED joystick with battery indicator, mode and profile button, speed selection and horn
Options
* LCD joystick with colour screen, battery indicator, mode and profile button, speed selection, horn and 3.5mm mono jacks
* LCD joystick with heavy duty gimble
* Optional joystick knobs
* Retractable joystick mount
* Stealth gatlin midline mount
* Enhanced steering performance (ESP) unit
* Omni control module with infra-red
* R-Net Bluetooth mouse module
* Input/output module
* Attendant control joystick
* Co-pilot attendant control
* Remote stop system
* LED lighting package
* Alternate drive systems - compact joystick, compact lite joystick, compact advanced joystick, mini joystick, manual and powered chin boom, sip 'n' puff, total head array, proportional foot control, proportional head control, tablet control, VIC proportional finger control
Batteries
* 2 x 60amp (Group 34) batteries
* 8amp battery charger
Motor
* 2 x two pole motors
* Single pull tab disengagement mechanism
Transport
* Front and rear transit approved tie-down points
Option
* Permolock C3 locking base and dual locking pin kit
Colours
* Choice of 6 shroud colours
* Choice of 14 hub cap colours
Brakes
* Electromagnetic brakes
Standard accessories
* Choice of 5 calf pad sizes
* Bodypoint non-padded hip belt
* See Options
Considerations
Transport Accessibility
The space allowed on public transport for carrying mobility equipment is an area of 1300mm by 800mm.
Wheelchair spaces
All new Sydney buses feature special 'kneeling suspension' and a ramp to provide easy access for less mobile passengers.
There are spaces for two wheelchairs on the new buses. These will accommodate most manual and electric wheelchairs with maximum length 1250mm, maximum width 750mm, maximum turning circle1500mm and maximum weight 200kg.
For safety reasons, passengers in wheelchairs are advised to face the back of the bus, bracing their wheelchair against the side of the space, applying the brakes and securing the seat belt of the wheelchair.
Wheelchair accessible buses display a blue and white wheelchair sign on the front of the bus, and on the easy access door.
Occupied Wheelchair in a Car
A person sitting in a wheelchair within a car or van requires certification and RMS (Roads and Maritime Services) approval for the wheelchair and occupants restraint system where the wheelchair or occupant are restrained to the vehicle structure. RMS approval is not required for a postural support, such as a harness, that is only attached to the wheelchair and not to the vehicle.
Wheelchair Restraints
When transporting a person in a wheelchair in a car or van, both the occupant and the wheelchair require a Roads and Maritime Services (RMS) approved restraint system. The wheelchair and the occupant need to be separately secured to the vehicle itself.
RMS approval is not required for a postural support, such as a harness that supports the user in the wheelchair but is not part of the vehicle restraint system.
The use of a headrest is not legally required but strongly recommended. Easily detachable, folding headrests which fit a wheelchair with standard push handles are available. Refer to section Wheelchair, Scooter, Cushions, ramps / Postural Supports - Seating System: Restraint+Head+Back+Seats
Place Of Manufacture
Permobil (Sweden/United States of America)
www.permobil.com
Price Guide
Subject to full assessment and evaluation - $10,000 +
