More Details

Frame
* Rigid steel chassis
* Adjustable suspension system
* Adjustable front anti-tip wheels

Seat
* Adjustable seat width from 16 inches to 22 inches
* Adjustable seat depth from 16 inches to 22 inches
Options
* Power tilt-in-space from 0 degrees to 45 degrees
* 8 inches power seat elevate

Backrest
* Angle adjustable back canes from 85 degrees to 115 degrees
* Height adjustable push handles
* Sling upholstered back support (Not available on power tilt-in-space)
* Curved metal back support (22 inches fixed height)
Option
* Quick lock angle adjustable back canes

Headrest (optional)
* Leatherette headrest
* Stealth comfort plus headrest
* Universal headrest adaptor plate

Armrests
* Dual post, flip back, height adjustable armrests
* Choice of 2 arm pad lengths (10.5 inches and 14 inches)
Options
* Waterfall arm pads
* Corpus 3G arm pads (10 inches, 12 inches, 14 inches, 16 inches)
* Corpus 3G arm rest side supports

Legrests
* 70 degrees swing away leg rests
Option
* Centre mounted manual elevating leg rest from 90 degrees to 150 degrees

Footplates
* Choice of small or large plastic, flip up footplates
* Heel loops
Option
* Choice of small or large multi-axis, angle adjustable, aluminum, flip up footplates

Wheels
* 14 inches x 3 inches drive wheels
* Choice of pneumatic or flat free (with gel insert) tyres
Option
* 14 inches x 3 inches pneumatic snow tyres

Castors
* 8 inches x 2.5 inches polyurethane castors

Controls
* R-Net electronics coupled with Intelligent Control System (ICS)
* LED joystick with battery indicator, mode and profile button, speed selection and horn
Options
* LCD joystick with colour screen, battery indicator, mode and profile button, speed selection, horn and 3.5mm mono jacks
* LCD joystick with heavy duty gimble
* Optional joystick knobs
* Retractable joystick mount
* Stealth gatlin midline mount
* Enhanced steering performance (ESP) unit
* Omni control module with infra-red
* R-Net Bluetooth mouse module
* Input/output module
* Attendant control joystick
* Remote stop system
* LED lighting package
* Alternate drive systems - compact joystick, compact lite joystick, compact advanced joystick, mini joystick, manual and powered chin boom, sip 'n' puff, total head array, proportional foot control, proportional head control, tablet control, VIC proportional finger control

Batteries
* 2 x 60amp (Group 34) batteries
* 8amp battery charger

Motor
* 2 x two pole motors
* Single pull tab disengagement mechanism

Transport
* Front and rear transit approved tie-down points
Option
* Permolock C3 locking base and dual locking pin kit

Colours
* Choice of 6 shroud colours
* Choice of 14 hub cap colours

Brakes
* Electromagnetic brakes

Standard accessories
* Choice of 2 calf pad sizes
* Leatherette calf support
* Bodypoint non-padded hip belt
* See Options

Considerations

Transport Accessibility
The space allowed on public transport for carrying mobility equipment is an area of 1300mm by 800mm.

Wheelchair spaces
All new Sydney buses feature special 'kneeling suspension' and a ramp to provide easy access for less mobile passengers.

There are spaces for two wheelchairs on the new buses. These will accommodate most manual and electric wheelchairs with maximum length 1250mm, maximum width 750mm, maximum turning circle1500mm and maximum weight 200kg.

For safety reasons, passengers in wheelchairs are advised to face the back of the bus, bracing their wheelchair against the side of the space, applying the brakes and securing the seat belt of the wheelchair.

Wheelchair accessible buses display a blue and white wheelchair sign on the front of the bus, and on the easy access door.

Occupied Wheelchair in a Car
A person sitting in a wheelchair within a car or van requires certification and RMS (Roads and Maritime Services) approval for the wheelchair and occupants restraint system where the wheelchair or occupant are restrained to the vehicle structure. RMS approval is not required for a postural support, such as a harness, that is only attached to the wheelchair and not to the vehicle.

Wheelchair Restraints
When transporting a person in a wheelchair in a car or van, both the occupant and the wheelchair require a Roads and Maritime Services (RMS) approved restraint system. The wheelchair and the occupant need to be separately secured to the vehicle itself.
RMS approval is not required for a postural support, such as a harness that supports the user in the wheelchair but is not part of the vehicle restraint system.
The use of a headrest is not legally required but strongly recommended. Easily detachable, folding headrests which fit a wheelchair with standard push handles are available. Contact the supplier or refer to section Wheelchair, Scooter, Cushions, ramps / Postural Supports - Seating System: Restraint+Head+Back+Seats

Place Of Manufacture

Permobil (Sweden/United States of America)
www.permobil.com

Price Guide

Subject to full assessment and evaluation - $8,000 +

Models

Paediatric model also available - K300 PS Junior

Options

Seat
* Power tilt-in-space
* 8 inches power seat elevate

Backrest
* Quick lock angle adjustable back canes

Armrests
* Waterfall arm pads
* Corpus 3G arm pads
* Corpus 3G arm rest side supports

Legrests
*Centre mounted manual elevating leg rest

Footplates
*Choice of footplates

Wheels
*14 inches x 3 inches pneumatic snow tyres

Headrest
* Leatherette headrest
* Stealth comfort plus headrest
* Universal headrest adaptor plate

Controls
* LCD joystick with colour screen, battery indicator, mode and profile button, speed selection, horn and 3.5mm mono jacks
* LCD joystick with heavy duty gimble
* Optional joystick knobs
* Retractable joystick mount
* Stealth gatlin midline mount
* Enhanced steering performance (ESP) unit
* Omni control module with infra-red
*R-Net Bluetooth mouse module
* Input/output module
*Attendant control joystick
* Remote stop system
* LED lighting package
*Alternate drive systems

Transport
* Permolock C3 locking base and dual locking pin kit

Optional accessories
* Self-leveling cup holder
* Medical necessities bag
* Bag hooks
* Crutch holder
* Oxygen holder
* Fixed vent shelf
* Hand heater
* Tray
* Bodypoint padded hip belt
* Bodypoint chest strap

Additional Dimensions

Maximum speed.......8km/h, 10km/h (Optional)
Range...............25.5km
Length (overall)....1020mm
Turning radius......640mm
Maximum slope.......10 degrees up / 6 degrees down
Seat elevator/lift..200mm
Tilt................0 degrees to 45 degrees (power)
Recline.............85 degrees to 115 degrees (manual)
Elevating leg rests.70 degrees (fixed); 90 degrees to 150 degrees (manual)

Maintenance

All wheelchairs require regular maintenance. Refer to User Manual for specific details

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.

Licence & Insurance Requirements

In NSW, motorised wheelchairs that weigh less than 110 kg and cannot travel at more than 10 km/h do not have to be registered, provided they are being used by a person with mobility problems. A person driving a motorised wheelchair under these circumstances is defined as a pedestrian under the Australian Road Rules and is permitted to travel on a footpath or nature strip adjacent to the road.

Vehicles exempt from registration are covered by the nominal defendant scheme (administered by the Motor Accidents Authority) if they are at fault in an accident in NSW on a road or road-related area and cause injury to another person. However, this cover is only valid in NSW.
