Short Description
A rigid frame electric wheelchair with a manual reclining backrest. The chair can be customised to suit individual needs and has an extensive range of options. The wheelchair features a front pivot bar and sprung rear suspension (SRS). The wheelchair offers a choice of three grades of ride - soft, medium or hard. The backrest folds forward for transportation.
Options
*Powered reclining backrest (160 degrees seat to back angle).
*Manual reclining backrest (using hand wheel or changing nut and bolt
position).
*Powered tilt in space seat.
*Powered vertical seat lift
*Attendant / dual control, Chin control
*Joystick module with horn / split system.
*Tray control
*24 or 38 amp/hr batteries
*Elevating legrests / power elevating legrest.
*Larger aluminium footrests
*Moulded headrest extension
*Adjustable swingaway thoracic supports and hip guides
*Heel loops
*Armrest trough
*Tray: lift away and fold down
*Tray: slide in
*320mm x 55mm rear wheel
*Dual front wheel castors (200mm)
*Stump supports
*Skirt guards for drop down arms
*Quick release seat frame for lifing seat off base to transport wheelchair
*The series can be converted to front wheel drive.
Seating options:
*Plush Seat & Back Upholstery
*Basic Foam on Ply Upholstery (can be provided uncovered to enable custom modification by seating professionals)
*Normal vinyl slung upholstery
*Basic Frames for mounting off the shelf backrests
or combinations of any of the above
| Specification |
Standard |
| Armrest Height (from seat) |
From 150 mm to 350 mm |
| Backrest Height |
500 mm |
| Load Capacity (supplier stated) |
125 kg |
| Seat Depth |
From 370 mm to 460 mm (in 30mm increments) |
| Seat Height |
530 mm |
| Seat Width |
From 370 mm to 520 mm (in 30mm increments) |
| Width |
680 mm |
Additional Dimensions
Complete chair:
Overall length 1140mm
Overall height 1000mm
Weight Overall 78.5kg
Diameter-Castors 250mm
Diameter-Wheels 300mm
Backrest Height 500mm
Performance Specifications:
Batteries 2x12v 24 Amp or 38 Amp dry cell sealed.
Speed range 0 - 7 kph
More Details
Series 7 is based on the S6 but has a sprung rear suspension system to provide a softer ride. This is especially useful for people with Osteo Genesis Imperfecta and people who cannot tolerate sharp jolts common in other makes of wheelchairs
Frame: - Stainless steel main frame with aluminium housing at the front of the chair under the seat.
- Auto paint on the body work - available in grey as standard or in a range of colours.
Seating: - The standard seat is padded and upholstered with lumbar and lateral contouring.
- A safety lever and button, both under the front seat need to be
released together for the seat to be removed.
- Any type of seating system can then be fitted.
- The standard seat comes with manual recline either with a strut and bolt lock style reclining mechanism as standard, or option of a manual hand wheel.
- Power recline is also an option.
- Recline range - 5 degrees to 45 degrees. Reclines from vertical.
- Backrest can fold forward.
- Seat width is adjustable from 370mm - 520mm.
- Seat depth is adjustable from 370mm - 460mm.
- The seat is able to be slightly tilted and height adjusted at the
Glide factory.
Armrests: - Full length and fully upholstered. Height can be adjusted and armrests can drop down to seat for transportation. Optional flip-up armrests.
Leg Supports: - Swing away and removable with lift up metal foot plates.
- Power elevating legrests are optional.
- Calf strap provided as standard.
Controls: - Programmable controller can be mounted on the left or right hand side and has a proportional joystick control.
- There is a push button on/off switch with a LED battery charge
indicator.
- For electric recline back, there are up and down (arrow) button
for recline and tilt.
- Control unit can be choosen for individual need.
Batteries: - Two 24 or 38 amp/hr gel batteries are housed under the frame and removable with basic tools.
Motors: - Can be disengaged by turning a knob in the centre of each rear wheel.
Brakes: - Electro-dynamic brakes automatically stop the wheelchair when the joystick is released.
- Manual brakes are on the rear wheels.
Wheels: - Rear 300mm x 80mm pneumatic. Front - single or dual castors 200mm pneumatic. Rear anti-tip wheels.
Glide 6 & 7 powered wheelchairs can have both a battery powered adjustable height seat and battery powered tilt in space on the one chair.
Place Of Manufacture
WA Australia
Licence & Insurance Requirements
Registration requirements
In NSW, motorised wheelchairs that weigh less than 110 kg and cannot travel at more than 10 km/h do not have to be registered, provided they are being used by a person with mobility problems. A person driving a motorised wheelchair under these circumstances is defined as a pedestrian under the Australian Road Rules and is permitted to travel on a footpath or nature strip adjacent to the road.
Vehicles exempt from registration are covered by the nominal defendant scheme (administered by the Motor Accidents Authority) if they are at fault in an accident in NSW on a road or road-related area and cause injury to another person. However, this cover is only valid in NSW.
