Short Description
Gamma seating system features a height adjustable base, tilt in space, anterior seat tilt and backrest recline. Includes various adjustable postural supports. The base is on castors and the two rear castors are lockable. Three sizes are available as a Basic or Standard model.
Models
Basic model
The basic Gamma chair includes arm rests, two piece back, footplates but not sandals, hip pads, push handles, tray.
GC1 Basic Size 1
GC2 Basic Size 2
GC3 Basic Size 3
Standard model
The standard seating features (in addition to the above) headrest, thoracic pads, lap strap, knee blocks and sandal foot supports.
GC1 Standard Size 1
GC2 Standard Size 2
GC3 Standard Size 3
Options
Activity Frame
Knee blocks
Chest pad
Multi Grip Headrest (wrap around style)
Shoulder harness
Shoulder protractors
Thoracic pads
Abduction block
Elbow blocks
Full grab bar
Sandals
| Specification |
Gamma 1 |
Gamma 2 |
Gamma 3 |
| Armrest Height (from seat) |
Unknown |
Unknown |
Unknown |
| Backrest Height |
From 350 mm to 455 mm |
From 390 mm to 495 mm |
From 430 mm to 535 mm |
| Load Capacity (supplier stated) |
18 kg |
25 kg |
32 kg |
| Seat Depth |
From 185 mm to 265 mm |
From 230 mm to 320 mm |
From 270 mm to 370 mm |
| Seat Height |
From 335 mm to 520 mm |
From 335 mm to 520 mm |
From 335 mm to 520 mm |
| Seat Width |
From 160 mm to 330 mm |
From 180 mm to 330 mm |
From 180 mm to 330 mm |
Additional Dimensions
Gamma 1 Gamma 2 Gamma 3
Weight Overall 28kg 31kg 34kg
More Details
Sizes
- Size 1 accommodates children in the approximate age range of 1 to 5 years.
- Size 2 accommodates children in the approximate age range of 3 to 8 years.
- Size 3 accommodates children in the approximate age range of 5 to 10 years.
. Gamma has a high - low base. The lowest seat height on size one allows Gamma to glide easily underneath a nursery table whilst rising to high chair height.
.The seat can be horizontal, inclined or reclined, the whole system can tilt in space and almost every adjustment can be fine tuned individually so any asymmetry or discrepancy in limb length can be accommodated with a minimum of effort.
Features
. Individually adjustable footplates with sandals.
. Adjustable hip support pads.
. Rear pull hip strap.
. Adjustable upper back.
. Push handle.
. Rear locking castors.
. Swing away kneeblocks.
. Armrests and activity tray.
. Adjustable lumbar support pad.
. Thoracic pads with chest strap.
. Adjustable headrest.
Place Of Manufacture
Jenx (UK)
Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For a fact sheet about standards contact us or visit www.ilcaustralia.org/home/standards.asp
