More Details

Frame
* Heavy duty, two in line mid wheel drive motors
* Frame is reinforced with heavy duty springs on front anti tip wheels
* Base cover is available in a variety of colours

Upholstery
* The upholstery is vinyl

Seat
* Standard, heavy duty, contoured. 105 degree fixed angle high backrest

Armrests
* Fixed desk style

Controls
* Joystick, adjustable / programmable
* The wheelchair is operated via a joystick control which can be programmed for speed and sensitivity

Footplates
* Single, lift up, adjustable height and angle

Drive Wheels
* 410mm diameter solid

Rear Castors
* 230mm diameter solid

Front Anti-tip Wheels
* 200mm diameter

Brakes
* Electronic regenerative disc brakes

Transporting
* The chair dismantles by removing the seat from the base

Freewheeling
* Easy front access dual free wheel levers

Batteries
* Two 12 volt 70 amp/hr

Battery Charging
* Is achieved by connecting the charger provided to a mains power point and plugging it into the chair at the marked charging terminal on the underside of the seat

Considerations

The space allowed on public transport for carrying mobility equipment is an area of 1300mm by 800mm.

Wheelchair spaces
All new Sydney buses feature special 'kneeling suspension' and a ramp to provide easy access for less mobile passengers.

There are spaces for two wheelchairs on the new buses. These will accommodate most manual and electric wheelchairs with max. length 1250mm, max. width 750mm, max. turning circle1500mm, and max weight 200kg.

For safety reasons, passengers in wheelchairs are advised to face the back of the bus, bracing their wheelchair against the side of the space, applying the brakes and securing the seat belt of the wheelchair.

Wheelchair accessible buses display a blue and white wheelchair sign on the front of the bus, and on the easy access door.

Place Of Manufacture

Pride Mobility (USA)

Price Guide

Call supplier for pricing
Price on application from GTK Rehab

Models

One model is available

Options

* 70 degree heavy duty legrests
* Lap belt
* Rear basket
* Oxygen tank holder
* Walker holder
* Cane / crutch holder
* Safety flag
* Heavy duty Synergy Seat
* 4, 55 AH batteries (17kg each) for extended range (32km)

Additional Dimensions

Overall length 1190mm
Weight overall 103kg
Weight of base 74kg
Speed Range 6.4km/h
Turning radius 685mm

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.

Licence & Insurance Requirements

In NSW, motorised wheelchairs that weigh less than 110 kg and cannot travel at more than 10 km/h do not have to be registered, provided they are being used by a person with mobility problems. A person driving a motorised wheelchair under these circumstances is defined as a pedestrian under the Australian Road Rules and is permitted to travel on a footpath or nature strip adjacent to the road.

Vehicles exempt from registration are covered by the nominal defendant scheme (administered by the Motor Accidents Authority) if they are at fault in an accident in NSW on a road or road-related area and cause injury to another person. However, this cover is only valid in NSW.
