More Details

* This three wheeled wheelchair is designed for active people with good upper body strength, and for more passive users, with the optional attendant handlebars
* The chair has been tested to and complies with European Standard ISO 7176 Part 8 Strength and Fatigue Testing and is CE marked
* It is included in the Australian Register of Therapeutic Goods Device Class 1 Product Number 220213

Frame
* Construction is carbon fibre, anodised or powder coated aluminium and stainless steel
* Reclinable carbon fibre monocoque chassis. (Monocoque, meaning 'single shell' in French, is a construction technique that utilises the external skin to support some or most of the load)
* Nitrogen gas suspension
* All components are attached to the seat

Upholstery
* Four piece 15mm Velcro attached foam padding - Lycra (or optional Suede)

Seat
* Standard size 'fits most teens to adult' seat width 410mm excluding basic foam liner (included)
* Seat width is variable by padding
* Larger size (XL) seat 480mm is also available (Load capacity is160kg)
* Carbon fibre sculptured black seat has a curved anatomical shape designed to suit the user's body
* A basic lycra covered foam liner is included
* Seat height 460 - 490 mm

Cushions
* Four stages of seat cushioning are available
* 1) Standard 15 mm foam upholstery as detailed above
* 2) Dedicated Qbitus 50mmFoam Cushion
* 3) Dedicated ROHO Low Profile inflatable cell Pressure Cushion
* 4) Dedicated ROHO High Profile inflatable cell Pressure Cushion

Backrest
* For descending: the backrest is tipped back via the shock valve and more weight is on the castor. The brake lever is used for secure speed control
* For ascending: the backrest tips forwards to avoid instability and increase front wheel traction. As the backrest is tipped back, via the Nitrogen release valve, the footrest rises for the maximum ground clearance. The ground clearance is deliberately limited to discourage users from trying extreme terrain

Wheels
* Two large quick release wheels at the front that can take mountain bike tyres. A smaller wheel is located at the back
* All three tyres are pneumatic and available with puncture resistant technology
* The large rear castor (320mm diameter) can usually go over most obstacles
* The wheels have an easily adjustable camber so that the chair can have a slimmer profile for going through doorways and a wider (more stable) 24 degree camber for outdoor activities
* The wheel tilt can be easily altered by rotating a cross shaft underneath the seat: at its slimmest, the K2 is 710mm wide and when fully adjusted it broadens out to 870mm

Brakes
* There is a brake drum inside each wheel hub, which is operated by the brake levers
* If travelling at speed or downhill and the left lever only is pulled, the chair will pull to the left, and vice-versa. However, caution and skill are required to avoid spinning around 360 degrees. In normal use, the chair is steered like a traditional chair, by differential pushing of the front push rims

Folding
* The chair is made from removable components that can be dismantled using conventional tools
* The wheels come off, the footrest slides up, and the rear assembly unclips and folds against the seat back

Place Of Manufacture

United Kingdom

Price Guide

The basic wheelchair is 3595, approx AU$6363. The price depends on the UK pound and Australian dollar conversion rate at the time of purchase.

Models

Although there is one base model, the wheelchair is predominately split into two specifications, namely the 'Active', supplied with user controlled brakes, or the 'Passive', with handlebar mounted, attendant controlled braking. Any combination is possible and active users often opt for rear handlebars (without attendant brakes levers fitted).

Options

* Dyna Brake
* Suede upholstery
* Speedometer
* Rear push bar (with or without attendant brakes)
* Seat belt
* Lap belt
* Wheel loops
* Three different leg lengths
* Extra large seat
* Attendant umbrella mount
* Armrests (retractable)
* 24" smooth front wheels

Additional Dimensions

Weight of Heaviest Part 8.9kg
Length 1140mm
Height 820mm
Width 710mm
Seat Height 460mm to 490mm (with tilting seat)
Folded Length 840mm

Standards

Standards
Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards

TGA
Many of the items on the ILC NSW website are categorised as a Medical Device. Medical devices that are approved for use in Australia have been entered into a national database called the Australian Register of Therapeutic Goods (ARTG), which is maintained by the Therapeutic Goods Administration (TGA). You can ask the supplier for the ARTG number for the device you wish to purchase and search the ARTG for the entry. To access information on the ARTG visit www.tga.gov.au

When buying a medical device it is advisable to only choose a medical device that is recommended by a healthcare professional and has been included on the ARTG.
