Short Description
A mid wheel drive indoor/outdoor powered wheelchair with 260mm drive wheels and dynamic shark fully programmable controller. Features six wheels on the ground technology with obstacle climb suspension on the front castors. Height adjustable seat with semi reclining backrest and adjustable armrests. Options are available.
Options
Swing away legrests.
Elevating legrests.
Seat sizes 460 x 500mm, 500 x 500mm
Models
Maverick 10 - smaller chair with swivel seat
Maverick 12 - larger chair with four post seat (non swivel)
| Specification |
Standard |
| Armrest Height (from seat) |
Unknown |
| Backrest Height |
Unknown |
| Load Capacity (supplier stated) |
136 kg |
| Seat Depth |
460 mm |
| Seat Height |
From 550 mm to 660 mm (from ground) |
| Seat Width |
From 460 mm to 510 mm (armrests are width adjustable) |
| Width |
610 mm |
Additional Dimensions
Length 860 mm
Height 1070 - 1120 mm
Weight 60 kg
More Details
Frame
Rigid frame.
Low centre of gravity.
Front and rear suspension.
No rear tipping on footplate standing
. Reflectors side and rear
Seat
Captains Seat standard size 460 x 460mm. Swivels through 360 degrees.
Height adjustable single post seat with reclining backrest.
Manually reclining backrest.
Seat may be replaced with choice of cushion.
Armrests
Lift up. Height and width adjustable
Footplate
Single fold up footplate. Adjustable in height and depth.
Wheels / Castors
260mm/ 10 inches pneumatic tyres on middle wheels.
Solid castors front and back
Controls
Swing back, retractable controller arm.
Dynamic PG VR-2 shark controller, fully programmable. Features buttons for on / off, horn, speed control (hare and tortoise buttons)
Battery and Charger
Off board 4 amp charger. 2 x 12V 30-40 a/h battery.
Factors To Consider
The space allowed on public transport for carrying mobility equipment is an area of 1300mm by 800mm.
Wheelchair spaces
All new Sydney buses feature special 'kneeling suspension' and a ramp to provide easy access for less mobile passengers.
There are spaces for two wheelchairs on the new buses. These will accommodate most manual and electric wheelchairs with maximum length 1250mm, maximum width 750mm, maximum turning circle1500mm and maximum weight 200kg.
For safety reasons, passengers in wheelchairs are advised to face the back of the bus, bracing their wheelchair against the side of the space, applying the brakes and securing the seat belt of the wheelchair.
Wheelchair accessible buses display a blue and white wheelchair sign on the front of the bus, and on the easy access door.
Maintenance
Include the statement ... All wheelchairs require regular maintenance. Refer to User Manual for specific details
Licence & Insurance Requirements
In NSW, motorised wheelchairs that weigh less than 110 kg and cannot travel at more than 10 km/h do not have to be registered, provided they are being used by a person with mobility problems. A person driving a motorised wheelchair under these circumstances is defined as a pedestrian under the Australian Road Rules and is permitted to travel on a footpath or nature strip adjacent to the road.
Vehicles exempt from registration are covered by the nominal defendant scheme (administered by the Motor Accidents Authority) if they are at fault in an accident in NSW on a road or road-related area and cause injury to another person. However, this cover is only valid in NSW.
Standards
Specific Australian Standards or other Standard(s) may be applicable for materials, manufacturing processes, or installation of some types of equipment. Compliance with relevant Standards is indicated by written certification that a product has been tested and assessed as compliant with specific Standards. Purchasers are advised to check with the supplier or manufacturer of this item as to its compliance with relevant Standard(s).
Place Of Manufacture
Taiwan
