Short Description

A battery powered rear wheel drive wheelchair with a rigid steel frame. It features a contoured padded captain style seat with a folding backrest. The seat and the footplates are adjustable forwards and backwards. The armrests are height and width adjustable. The wheelchair can be dismantled for transport. An optional curb climber is available. It is available in one size.

Options

* Curb climber

Models

One model is available
Product Code: Wckp10

Additional Dimensions

Height 970 mm
Length 925 mm
Weight of heaviest part 24 kg (base)
Weight 49.46 kg
Maximum Incline (gradient) 12 degrees
Maximum Speed 6 kmph
Maximum Range 16 - 20 km
Weight with batteries 49.46 kg
Weight w/o batteries 34.76 kg

More Details

Frame
Rigid aluminium alloy frame in silvery black colour

Seat
* Contoured padded seat
* Adjustable forwards and backwards using tools included

Backrest
* Folding (forwards to seat)
* Adjusts to four different angles

Armrests
Adjustable in height and width

Footplates
* Adjustable forwards and backwards
* Lift up
* Adjustable height

Motor
180 watt

Controls
* Joystick Shark VR2 controller
* Controller can be switched for left or right hand usage

Batteries
* 2 x 12v 22 amp hour batteries
* Quick release battery pack

Rear Wheels
320 mm?

Front Castors
200 mm

Transporting
Fold backrest. Remove seat from base. Remove batteries and legrests

Factors To Consider

The space allowed on public transport for carrying mobility equipment is an area of 1300mm by 800mm.

Wheelchair spaces
All new Sydney buses feature special 'kneeling suspension' and a ramp to provide easy access for less mobile passengers.

There are spaces for two wheelchairs on the new buses. These will accommodate most manual and electric wheelchairs with max. length 1250mm, max. width 750mm, max. turning circle1500mm, and max weight 200kg.

For safety reasons, passengers in wheelchairs are advised to face the back of the bus, bracing their wheelchair against the side of the space, applying the brakes and securing the seat belt of the wheelchair.

Wheelchair accessible buses display a blue and white wheelchair sign on the front of the bus, and on the easy access door.

Licence & Insurance Requirements

Registration requirements
In NSW, motorised wheelchairs that weigh less than 110 kg and cannot travel at more than 10 km/h do not have to be registered, provided they are being used by a person with mobility problems. A person driving a motorised wheelchair under these circumstances is defined as a pedestrian under the Australian Road Rules and is permitted to travel on a footpath or nature strip adjacent to the road.

Vehicles exempt from registration are covered by the nominal defendant scheme (administered by the Motor Accidents Authority) if they are at fault in an accident in NSW on a road or road-related area and cause injury to another person. However, this cover is only valid in NSW.

Standards

For some types of equipment, specific Australian or other Standard(s) are applicable to the materials used in and the manufacturing processes applied to and the installation of products. Compliance with relevant Standards is indicated by written certification that a product has been tested and assessed as compliant with specific Standards. Purchasers are advised to check with the supplier or manufacturer of an item as to its compliance with the relevant Standard(s).

Place Of Manufacture

Asia
