More Details

Frame
* Lightweight aluminum tubing with powder coated finish available in two colours - red hot and black abyss
* Flush mount seat rails for lower seat-to-floor height and ease of transfer

Upholstery
* Synthetic nylon

Seat
* Standard slung seat
* Available in a range of seat widths and depths (5 sizes)

Backrest
* Fitted with standard slung nylon style backrest
* A tension adjustable backrest with a padded overlay is optional
* Angle adjustable back canes or 8" fixed bend
* Can be fitted with or without push handles
* Adjustable height 305mm to 410mm or 380mm to 480mm

Armrest
* Fitted with flip around tubular armrests
* Option for height adjustable T-bar drop in armrests in desk or full length arm pad
* Can be fitted with Drop-in side guards

Legrest
* Fitted with 70 degree bi-directional swing away legrests
* Can be fitted with elevating legrests with calf pad

Footplate
* Standard model is lift - up style footplates with nylon heel straps
* Can be fitted with angle adjustable option

Brakes
* Standard push lock brakes
* Can be fitted with pull to lock, scissor lock or brake extensions

Wheels
* Quick release 660mm wheel
* Optional spoke, spinergy or mag style wheels in several different diameters

Castors
* Standard 100mm pneumatic castor
* Available in 4 different dimensions with long or short forks

Place Of Manufacture

United States of America

Price Guide

Call supplier for pricing
Price on application from ILS

Models

Only one model available.

Options

* Rear adjustable anti tips
* Drop in side guards
* Amputee axle mount
* Adjustable tension back
* Angle adjustable back canes
* Elevating legrests
* Synergy back rest
* Spinergy Spox wheels
* Natural Fit handrim
* Spoke protector
* Composite Mag wheels
* Scissor lock
* Brake extension lock

Additional Dimensions

Seat Rear Height...............................From 355 mm to 480 mm
(in 25mm increments)
Seat Front Height.............................. From 380 mm to 485 mm
(in 25mm increments)
Wheel Diameter (Rear).................... 510, 560, 610 or 660 mm
Castor Diameter............................... 100, 130, 155 or 205 mm

Standards

Some assistive technology needs to meet Australian or other standards. Standards may relate to materials, manufacturing and installation. Products that meet Australian or international standards will have written certification. To find out if a product meets Australian Standards ask the supplier to show you the certificate. For more information about standards also see
www.ilcnsw.asn.au/home/assistive_technology/standards
